Alpine

R2-W12D2

R2-W12D2

Regular price $379.95 USD
Regular price $409.95 USD Sale price $379.95 USD
Sale Sold out
Shipping calculated at checkout.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes. A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ-Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for additional protection to the cone. These subwoofers feature Alpine’s High Amplitude Multi-Roll (HAMR) Surround technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
  • Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
  • Polypropylene/Ceramic Composite Dust Cap
  • Kevlar Reinforced Pulp Cone High-Performance subwoofers  Twist-Lock Grille Mount System
  • High-Amplitude Multi-Roll (H.A.M.R.) Surround
  • Large Double-Stacked Magnets
  • 12” R2-Series DVC Subwoofer with Cosmetic Trim Ring
  • 2 Jumper Wires for DVC Configuration
  • 750W RMS
  • 2250W Peak Power Handling
  • Frequency Response: 24Hz-200Hz
  • Sensitivity (1W/1m): 84.5dB
  • Nominal Impedance: 2Ω + 2Ω
  • Voice Coil: 65mm 
  • X-Max: 20mm
  • Magnet Weight: 144oz
  • Mounting Depth: 6-1/2” (152mm)
  • Cutout Size: 10-7/8” (231mm)
  • Push-Type Speaker Terminals (Up to 8AWG Wire Size)
  • CTA-2031 Compliant
