Alpine

R2-W10D4

Name: R2-W10D4
Brand: Alpine
Price: 329.95 USD
Availability: OutOfStock

$329.95 USD

~~$359.95 USD~~ $329.95 USD

Sale Sold out

Shipping calculated at checkout.

{"id":8477317431606,"title":"R2-W10D4","handle":"r2-w10d4","description":"\u003cp\u003e\u003cspan data-mce-fragment=\"1\"\u003e\u003cspan data-mce-fragment=\"1\"\u003eThe 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes. A new polypropylene\/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non-stop bass performance. The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ-Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for additional protection to the cone.\u003c\/span\u003e\u003c\/span\u003e\u003c\/p\u003e\n\u003cp\u003e\u003cspan data-mce-fragment=\"1\"\u003e\u003cspan data-mce-fragment=\"1\"\u003eSpecifications:\u003c\/span\u003e\u003c\/span\u003e\u003c\/p\u003e\n\u003cul\u003e\n\u003cli\u003eDual Voice Coil (DVC) Subwoofers with Configuration Jumpers\u003c\/li\u003e\n\u003cli\u003ePolypropylene\/Ceramic Composite Dust Cap\u003c\/li\u003e\n\u003cli\u003eKevlar Reinforced Pulp Cone High-Performance subwoofers \u003c\/li\u003e\n\u003cli\u003eTwist-Lock Grille Mount System\u003c\/li\u003e\n\u003cli\u003eHigh-Amplitude Multi-Roll (H.A.M.R.) Surround\u003c\/li\u003e\n\u003cli\u003eLarge Double-Stacked Magnets\u003c\/li\u003e\n\u003cli\u003e10” R2-Series DVC Subwoofer with Cosmetic Trim Ring\u003c\/li\u003e\n\u003cli\u003e2 Jumper Wires for DVC Configuration\u003c\/li\u003e\n\u003cli\u003e750W RMS\u003c\/li\u003e\n\u003cli\u003e2250W Peak Power Handling\u003c\/li\u003e\n\u003cli\u003eFrequency Response: 26Hz-200Hz\u003c\/li\u003e\n\u003cli\u003eSensitivity (1W\/1m): 82.4dB  \u003c\/li\u003e\n\u003cli\u003eNominal Impedance: 4Ω + 4Ω\u003c\/li\u003e\n\u003cli\u003eVoice Coil: 65mm \u003c\/li\u003e\n\u003cli\u003eX-Max: 20mm\u003c\/li\u003e\n\u003cli\u003eMagnet Weight: 123oz\u003c\/li\u003e\n\u003cli\u003eMounting Depth: 6” (152mm)\u003c\/li\u003e\n\u003cli\u003eCutout Size: 9-1\/16” (231mm)\u003c\/li\u003e\n\u003cli\u003ePush-Type Speaker Terminals (Up to 8AWG Wire Size)\u003c\/li\u003e\n\u003cli\u003eCTA-2031 Compliant\u003c\/li\u003e\n\u003c\/ul\u003e","published_at":"2023-07-07T11:34:02-05:00","created_at":"2023-07-07T11:34:02-05:00","vendor":"Alpine","type":"subwoofer","tags":["subwoofer"],"price":32995,"price_min":32995,"price_max":32995,"available":false,"price_varies":false,"compare_at_price":35995,"compare_at_price_min":35995,"compare_at_price_max":35995,"compare_at_price_varies":false,"variants":[{"id":45698467594550,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"R2-W10D4","public_title":null,"options":["Default Title"],"price":32995,"weight":11340,"compare_at_price":35995,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-front.jpg?v=1688748118","\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-Side.jpg?v=1688748118","\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-back.jpg?v=1688748118"],"featured_image":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-front.jpg?v=1688748118","options":["Title"],"media":[{"alt":null,"id":34431578505526,"position":1,"preview_image":{"aspect_ratio":1.333,"height":750,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-front.jpg?v=1688748118"},"aspect_ratio":1.333,"height":750,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-front.jpg?v=1688748118","width":1000},{"alt":null,"id":34431578538294,"position":2,"preview_image":{"aspect_ratio":1.333,"height":750,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-Side.jpg?v=1688748118"},"aspect_ratio":1.333,"height":750,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-Side.jpg?v=1688748118","width":1000},{"alt":null,"id":34431578472758,"position":3,"preview_image":{"aspect_ratio":1.333,"height":750,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-back.jpg?v=1688748118"},"aspect_ratio":1.333,"height":750,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/R2-W10D4_10-inch-R-Series-Subwoofer-with-Dual-4-Ohm-Voice-Coils-back.jpg?v=1688748118","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cp\u003e\u003cspan data-mce-fragment=\"1\"\u003e\u003cspan data-mce-fragment=\"1\"\u003eThe 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes. A new polypropylene\/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non-stop bass performance. The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ-Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for additional protection to the cone.\u003c\/span\u003e\u003c\/span\u003e\u003c\/p\u003e\n\u003cp\u003e\u003cspan data-mce-fragment=\"1\"\u003e\u003cspan data-mce-fragment=\"1\"\u003eSpecifications:\u003c\/span\u003e\u003c\/span\u003e\u003c\/p\u003e\n\u003cul\u003e\n\u003cli\u003eDual Voice Coil (DVC) Subwoofers with Configuration Jumpers\u003c\/li\u003e\n\u003cli\u003ePolypropylene\/Ceramic Composite Dust Cap\u003c\/li\u003e\n\u003cli\u003eKevlar Reinforced Pulp Cone High-Performance subwoofers \u003c\/li\u003e\n\u003cli\u003eTwist-Lock Grille Mount System\u003c\/li\u003e\n\u003cli\u003eHigh-Amplitude Multi-Roll (H.A.M.R.) Surround\u003c\/li\u003e\n\u003cli\u003eLarge Double-Stacked Magnets\u003c\/li\u003e\n\u003cli\u003e10” R2-Series DVC Subwoofer with Cosmetic Trim Ring\u003c\/li\u003e\n\u003cli\u003e2 Jumper Wires for DVC Configuration\u003c\/li\u003e\n\u003cli\u003e750W RMS\u003c\/li\u003e\n\u003cli\u003e2250W Peak Power Handling\u003c\/li\u003e\n\u003cli\u003eFrequency Response: 26Hz-200Hz\u003c\/li\u003e\n\u003cli\u003eSensitivity (1W\/1m): 82.4dB  \u003c\/li\u003e\n\u003cli\u003eNominal Impedance: 4Ω + 4Ω\u003c\/li\u003e\n\u003cli\u003eVoice Coil: 65mm \u003c\/li\u003e\n\u003cli\u003eX-Max: 20mm\u003c\/li\u003e\n\u003cli\u003eMagnet Weight: 123oz\u003c\/li\u003e\n\u003cli\u003eMounting Depth: 6” (152mm)\u003c\/li\u003e\n\u003cli\u003eCutout Size: 9-1\/16” (231mm)\u003c\/li\u003e\n\u003cli\u003ePush-Type Speaker Terminals (Up to 8AWG Wire Size)\u003c\/li\u003e\n\u003cli\u003eCTA-2031 Compliant\u003c\/li\u003e\n\u003c\/ul\u003e"}

Product variants

Quantity

The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes. A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non-stop bass performance. The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ-Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for additional protection to the cone.

Specifications:

Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
10” R2-Series DVC Subwoofer with Cosmetic Trim Ring
2 Jumper Wires for DVC Configuration
750W RMS
2250W Peak Power Handling
Frequency Response: 26Hz-200Hz
Sensitivity (1W/1m): 82.4dB
Nominal Impedance: 4Ω + 4Ω
Voice Coil: 65mm 
X-Max: 20mm
Magnet Weight: 123oz
Mounting Depth: 6” (152mm)
Cutout Size: 9-1/16” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
