DS18

DS18 EQX7

Name: DS18 EQX7
Brand: DS18
Price: 79.95 USD
Availability: InStock

$79.95 USD

~~$89.99 USD~~ $79.95 USD

Sale Sold out

Shipping calculated at checkout.

{"id":9847759962422,"title":"DS18 EQX7","handle":"ds18-eqx7","description":"\u003cdiv class=\"card__header\"\u003e\n\u003ch2 class=\"card__title heading h3\"\u003eDescription\u003c\/h2\u003e\n\u003c\/div\u003e\n\u003cdiv class=\"card__section\"\u003e\n\u003cdiv class=\"rte text--pull\"\u003e\n\u003cdiv class=\"table-wrapper\"\u003e\n\u003ctable width=\"499\" data-mce-fragment=\"1\"\u003e\n\u003ctbody data-mce-fragment=\"1\"\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd width=\"150\" data-mce-fragment=\"1\"\u003eModel\u003c\/td\u003e\n\u003ctd width=\"349\" data-mce-fragment=\"1\"\u003eEQX7\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eBoost \/ Cut\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e12dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eS\/N ratio\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e100dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eFrequency Response\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e10Hz-50KHz +\/-1dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eMaximum Output voltage\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e8V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eTHD\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e0.005%\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eInput impedance\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e50mV- 3 V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eHead Room\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e20 dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eOutput impedance\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e2K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eInput impedance\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e20K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eStereo Separation\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e82 dB\/1 KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eOperating voltage\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e11V-15V Negative Ground\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eDimension(L x W x H)\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e7\" x 4.40\" x 1.18\"\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003c\/div\u003e\n\u003c\/div\u003e\n\u003c\/div\u003e","published_at":"2024-10-12T16:00:06-05:00","created_at":"2024-10-12T16:00:06-05:00","vendor":"DS18","type":"1-channel amp","tags":["Best Selling"],"price":7995,"price_min":7995,"price_max":7995,"available":true,"price_varies":false,"compare_at_price":8999,"compare_at_price_min":8999,"compare_at_price_max":8999,"compare_at_price_varies":false,"variants":[{"id":51014002377014,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":false,"featured_image":null,"available":true,"name":"DS18 EQX7","public_title":null,"options":["Default Title"],"price":7995,"weight":2268,"compare_at_price":8999,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-2000x2000_1800x1800_f5fda76a-e986-4ad9-89fa-cbc29d29be11.webp?v=1728766760","\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-TOP-RIGHT_1800x1800_68f4577c-5a18-4ff3-855e-b1fd674293b3.webp?v=1728766762","\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-TOP-LEFT_1800x1800_fb091928-a711-4716-acc9-6d56cd18bc28.webp?v=1728766764","\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-FRONT_1800x1800_b3b1780d-16c5-49bc-8e73-24217881d669.webp?v=1728766766","\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-BACK_1800x1800_1bedd3bb-020a-4518-b496-82e1aa2e30f0.webp?v=1728766769"],"featured_image":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-2000x2000_1800x1800_f5fda76a-e986-4ad9-89fa-cbc29d29be11.webp?v=1728766760","options":["Title"],"media":[{"alt":null,"id":43425200898358,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-2000x2000_1800x1800_f5fda76a-e986-4ad9-89fa-cbc29d29be11.webp?v=1728766760"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-2000x2000_1800x1800_f5fda76a-e986-4ad9-89fa-cbc29d29be11.webp?v=1728766760","width":1000},{"alt":null,"id":43425201029430,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-TOP-RIGHT_1800x1800_68f4577c-5a18-4ff3-855e-b1fd674293b3.webp?v=1728766762"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-TOP-RIGHT_1800x1800_68f4577c-5a18-4ff3-855e-b1fd674293b3.webp?v=1728766762","width":1000},{"alt":null,"id":43425201291574,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-TOP-LEFT_1800x1800_fb091928-a711-4716-acc9-6d56cd18bc28.webp?v=1728766764"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-TOP-LEFT_1800x1800_fb091928-a711-4716-acc9-6d56cd18bc28.webp?v=1728766764","width":1000},{"alt":null,"id":43425201520950,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-FRONT_1800x1800_b3b1780d-16c5-49bc-8e73-24217881d669.webp?v=1728766766"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-FRONT_1800x1800_b3b1780d-16c5-49bc-8e73-24217881d669.webp?v=1728766766","width":1000},{"alt":null,"id":43425202078006,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-BACK_1800x1800_1bedd3bb-020a-4518-b496-82e1aa2e30f0.webp?v=1728766769"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/www.bestsoundcaraudio.com\/cdn\/shop\/files\/EQX7-BACK_1800x1800_1bedd3bb-020a-4518-b496-82e1aa2e30f0.webp?v=1728766769","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cdiv class=\"card__header\"\u003e\n\u003ch2 class=\"card__title heading h3\"\u003eDescription\u003c\/h2\u003e\n\u003c\/div\u003e\n\u003cdiv class=\"card__section\"\u003e\n\u003cdiv class=\"rte text--pull\"\u003e\n\u003cdiv class=\"table-wrapper\"\u003e\n\u003ctable width=\"499\" data-mce-fragment=\"1\"\u003e\n\u003ctbody data-mce-fragment=\"1\"\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd width=\"150\" data-mce-fragment=\"1\"\u003eModel\u003c\/td\u003e\n\u003ctd width=\"349\" data-mce-fragment=\"1\"\u003eEQX7\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eBoost \/ Cut\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e12dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eS\/N ratio\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e100dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eFrequency Response\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e10Hz-50KHz +\/-1dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eMaximum Output voltage\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e8V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eTHD\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e0.005%\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eInput impedance\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e50mV- 3 V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eHead Room\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e20 dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eOutput impedance\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e2K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eInput impedance\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e20K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eStereo Separation\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e82 dB\/1 KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eOperating voltage\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e11V-15V Negative Ground\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr data-mce-fragment=\"1\"\u003e\n\u003ctd data-mce-fragment=\"1\"\u003eDimension(L x W x H)\u003c\/td\u003e\n\u003ctd data-mce-fragment=\"1\"\u003e7\" x 4.40\" x 1.18\"\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003c\/div\u003e\n\u003c\/div\u003e\n\u003c\/div\u003e"}

Product variants

Quantity

Model	EQX7
Boost / Cut	12dB
S/N ratio	100dB
Frequency Response	10Hz-50KHz +/-1dB
Maximum Output voltage	8V
THD	0.005%
Input impedance	50mV- 3 V
Head Room	20 dB
Output impedance	2K Ohms
Input impedance	20K Ohms
Stereo Separation	82 dB/1 KHz
Operating voltage	11V-15V Negative Ground
Dimension(L x W x H)	7" x 4.40" x 1.18"

View full details
