DS18 CF-X8TPNEO
DS18 CF-X8TPNEO
Regular price
$1,049.95 USD
Regular price
$1,099.95 USD
Sale price
$1,049.95 USD
Unit price
per
Description
Nominal Diameter | 8'' |
Nominal Impedance | 4 Ohms |
RMS Power Handling | 180W |
MAX Power Handling | 540W |
Sensitivity (1w/1m) | 95dB |
Frequency Response | 60Hz - 21KHz |
Body / Features | |
Enclosure Material | Injection PC+ABS |
Marine Grade Type | IP65 + UV Stable |
RGB LED | Integrated LED-RGB Speaker Lighting Integrated LED-RGB Acrylic Ring Lighting 6 Core Wires for Lighting and Speaker |
Grill Type | ABS+316 Stainless Metal Mesh |
Pair | Yes |
Clamps | Die-Cast adjustable (1" ~ 2") 360 Degree Rotation Mounting Buried Wire or Open Wire Mounting Optional, Included NBR Pad And Stainless Hardware (Screws,Stop Washers,Hexagon wrench, Safety Rope, Screw fastening Glue) |
Front Logo | Yes, Can be Rotated For Correct Angle Display |
Woofer Specifications | |
Voice Coil Diameter | 2" |
Cone Material | Waterproof Compress Paper + Carbon Fiber |
Surround Material | Soft PC Damping Glued |
Basket Material | PC Injection Molded Composite |
Magnet Material | Neodymium |
Magnet Grade | N40H |
Passive Radiator | 4" With LED RGB Light |
Tweeter Specifications | |
Voice Coil Diameter | 1" |
Type | Compression Driver with CNC Solid Aluminum Horn |
Diaphragm Material | PEN |
Magnet Material | Neodymium |
Crossover | 12dB with Over Power Protection |
Thiele & Small Parameters | |
Equivalent Volume | Vas - 17.5L |
Excursion (one way) | Xmax - 3mm |
Free Air Resonance | Fs- 62Hz |
Total Factor | Qts - 0.592 |
Speaker Measurements | |
Overall Diameter | 8.59" / 218.1mm |
Overall Depth | 13.89" / 352.9mm |
Overall Height | 12.37" / 314.3mm |
